FEATURES:
High specificity to gas of concern.
Long sensor life.
Quick response.
Continuous display of the gas concentration reading.
Built-in audible and visual alarms.
Easy to read LCD display.
GAS DETECTED:
Carbon Monoxide, Flammable, O2, Bromine, Chlorine, Diborane, Formaldehyde, H2, HCL, Carbon disulphide, HCN, HF, Hydrazine, Hydrogen Sulphide, NH3, NO2, Vinyl Chloride, Ethyl Mercaptan, Phosphine, Sulpher dioxide, Ammonia, Silane, Phosgene, VOC.
SPECIFICATIONS:
| Flamable |
Catalytic Bead Detector / Non Dispersive InfraRed Detector (NDIR) |
| Toxic & O2 |
Electrochemical |
| CO2 |
NDIR |
| VOC |
Photo ionization Detector (PID) |
| Accuracy |
Inherently +/- 2% (but also depends on the accuracy of the calibration gas & method) |
| Sampling |
Diffusion |
| Display |
3½ Digit LCD Display with low battery display |
| Hi & Lo Alarm View Keys |
To view the alarm set-points |
| Electronic Alarm |
85 db Audio Alarm, Visual LEDs |
| Power Source |
One 9V replaceable alkaline battery |
| Battery life |
Approx. 100 hrs |
| Operating Temperature Range |
0 to +50 °C |
| Operating Pressure |
Ambient +/- 10% |
| Enclosure |
ABS |
| Weight |
230 grams |
| Standard Accessories |
Carrying Case & Screw driver |
| Dimension |
H × W × D: 175 × 85 × 30 mm |
| Certification |
Intrinsic Safety (By CMRI Dhanbad)- EEx ia IIB T4 |
APPLICATIONS:
Confined Spaces
Fumigation
Occupational Safety & Health
Oil & Gas
Petrochemical Plants
Process Control
Research Laboratories
